Product Details:
|
| Features: | 2RS232 COM.Dual Lan MiNI Pc | Operating System: | Windows 10 |
|---|---|---|---|
| Hard Drive Type: | SSD+HDD | RAM Type: | DDR3 |
| Storage: | Support 1 MSATA SSD+1 2.5" SATA | CPU: | Integrated Intel Gemini Lake Single CPU |
| USB: | 4*USB2.0 2*USB3.0 Max Support +5V/1A | Size: | 235*200*53mm |
| Color: | Black | Support: | OEM And ODM |
| High Light: | DDR4 Industrial PC Computer,8USB Industrial PC Computer,1 LAN Industrial PC Embedded |
||
Edded PC Intel 10th Generation i5 i7 Fanless Industrial Mini PC Dual LAN WiFi Linux Mini PC
|
CPU
|
Intel® Celeron J1900, 4 Cores, 4 Threads, Base 2.0GHz, Turbo 2.4GHz, Fanless
|
|
CPU Optional
|
Intel® Core i3-8140U/8145U, 2 Cores, 4 Threads, Base 2.1GHz, Turbo 3.9GHz, Fanless
|
|
CPU Optional
|
Intel® Core i5-4278U, 2 Cores, 4 Threads, Base 2.6GHz, Turbo 3.1GHz, Fanless
|
|
CPU Optional
|
Intel® Core i5-7360U, 2 Cores, 4 Threads, Base 2.3GHz, Turbo 3.6GHz, Fanless
|
|
CPU Optional
|
Intel® Core i5-8269U/8265U/8365U, 4 Cores, 8 Threads, Base 2.6GHz, Turbo 4.2GHz, Fanless
|
|
CPU Optional
|
Intel® Core i5-10210U, 4 Cores, 8 Threads, Base 1.6GHz, Turbo 4.2GHz, Fanless
|
|
CPU Optional
|
Intel® Core i7-4578U, 2 Cores, 4 Threads, Base 3GHz, Turbo 3.5GHz, Fanless
|
|
CPU Optional
|
Intel® Core i7-7500U/7600U, 2 Cores, 4 Threads, Base 2.7GHz, Turbo 3.5GHz, Fanless
|
|
CPU Optional
|
Intel® Core i7-8569/8565U, 4 Cores, 8 Threads, Base 2.8GHz, Turbo 4.7GHz, Fanless
|
|
Memory
|
2*SO-DIMM DDR4 Slot (Max 32GB)
|
|
Storage
|
1*MSATA/M.2, 1*SATA3.0 slot
|
|
BIOS
|
American Megatrends Inc. 5.6.5
|
|
Operation System
|
Windows 8/10, WES 10, LINUX
|
|
PXE
|
YES
|
|
Network Support
|
Intel i210/i211 Gigabit Network Connection
|
|
Video
|
Intel UHD Graphics
|
|
Audio
|
Realtek ALC662 @ Intel Bay Trail SoC - HD Audio Controller
|
|
Mini PCIE
|
1*mini PCIE-half port, 1*mini PCIE-full port
|
|
Antenna
|
2*inner RF cables and 2*external antennas
|
|
Functions
|
Watchdog, AWAL, RTC, WOL(ATX mode)
|
